QY-150A Illumination Sensor

Parameter

Illumination range: 0 ~ 200 Klux
Reaction time: 100ms
Ambient temperature: −20 ~ 80 ℃
Accuracy: 0.1 Klux
Weight: 210g

Principle characteristics

  Using photoelectric conversion module, the light intensity value into voltage, and then by the conditioning circuit to convert this voltage 0.2 to 2 V or 4 to 20 mA.

Small size, easy to install.
Shell structure design is reasonable, long service life.
Good sealing.
High precision measurement, good stability.
Long transmission distance, strong resistance to external interference.

Measurement object

Transmission interface

Using aviation plug design

Copper plated silver material
   Shell zinc plated
      Conductive stability
         Safe and reliable

Application areas

Practical case

Light is the most important conditions affecting plant growth and development, Illumination has played a catalytic role in plant growth. For the vast majority of plants, In the long sunshine conditions to promote growth, short day conditions induced dormancy.

Therefore, through the light sensor to observe the impact of light on the plant, adjust the most reasonable light intensity, Improve the yield of photosynthesis, so as to achieve the ultimate goal of optimizing agricultural production.

Product categories

In addition, we also provide universal and custom lighting sensors to meet the needs of different customers.
